Basic Info.
Model NO.
GTLS-12W
Shell Material
Steel Plate
Shell Protection Grade
IP55
Brand
Junke
Standard
ANSI 12.7
Application
Plug in Circuit Breaker
Waterproof Level
NEMA 3r
Protection Level
IP54
Material
0.8-1.5mm Electro-Galvanized Steel Sheet
Rated Voltage
120/240V
Rated Current
125A
Useing Range
Single Phase 3 Wire
Rated Phase
Dpn
Breaker
Ge Circuit Breaker
Enclosure Type
Surface /Flush
Transport Package
Wooden Package
Specification
CE ROHS
Trademark
OEM
Origin
Zhejiang Yueqing
HS Code
9028901100
Production Capacity
100000PCS/ Month
Product Description
GTLS series are economy load centers which can substitute some Load Centers.
They have been designed for safe, reliable distribution and control of electrical power as service
entrance equipment in residential, commercial and light industrial premises.
Specifications:
| Product Number | Front Type | Main Ampere Rated | Rating Voltage(V) | No.of Way |
| GTLS2-2WAY | flush/surface | 40,60 | 120/240 | 2 |
| GTLS4-4WAY | flush/surface | 40,100 | 120/240 | 4 |
| GTLS6-6WAY | flush/surface | 40,100 | 120/240 | 6 |
| GTLS8-8WAY | flush/surface | 40,100 | 120/240 | 8 |
| GTLS12-12WAY | flush/surface | 40,100 | 120/240 | 12 |
Features
- Made out of high quality steel sheet of up to 0.6-1.2mm thickness.
- Matt-finish polyester powder coated paint.
- Knockouts provided on all sides of the enclosure.
- Accept GE type 1" THQL breakers.
- Suitable for single-phase ,three-wire, rated current to 100A,sevice voltage to 120/240Vac.
- Wider enclosure offers ease or wiring and move heat dissipation.
- Flush and surface mounted designs.
- Knockouts for cable entry are provided on top, bottom of the enclosure.
