Basic Info.
Model NO.
UTHBT530
OEM
Yes
Factory
Yes
Transport Package
in Pallet
Specification
530
Trademark
UT
Origin
China
Product Description
Mute Type Hydraulic Breaker Features :
The specifications may vary with different excavators and are subject to change without prior notice for products improvement.
- The designed mute type model has smooth lines and applies the latest closed outer shell to protect host machine and MIC shock absorption to reduce noise
- From municipal construction to mine work, UT mute series product can meet various demands of the vast users.
- The breaking hammer is compact in structure, applicable to wide and ultra-strong attacking force and is the outstanding model with excellent performance cost and high-frequency breaking.
| Item/Model / | Unit | UT450 | UT530 | UT680 | UT750 | UT850 | UT1350 | UT1400 | UT1550 | UT1650 | UT1750 | UT1800 | UT1900 |
| Operating Weight | Kg | 150 | 190 | 340 | 480 | 580 | 1650 | 2000 | 2900 | 3250 | 4150 | 4200 | 4230 |
| Required oil flow | L/Min | 20-40 | 25-45 | 36-60 | 50-90 | 45-85 | 130-170 | 150-190 | 150-230 | 200-260 | 210-280 | 280-350 | 280-350 |
| Working pressure | Bar | 90-120 | 90-120 | 110-140 | 120-170 | 127-147 | 160-185 | 165-195 | 170-200 | 180-200 | 180-200 | 190-210 | 190-210 |
| Impact rate | Bpm | 700-1200 | 500-1100 | 500-900 | 400-800 | 400-800 | 400-650 | 400-800 | 400-800 | 250-400 | 250-350 | 230-320 | 230-320 |
| Chisel Dia. | mm | 45 | 53 | 68 | 75 | 85 | 135 | 140 | 155 | 165 | 175 | 180 | 190 |
| Hose Dia. | Inch | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1 | 1 | 1 | 1.1/4 | 1.1/4 | 1.1/4 | 1.1/4 |
| Suit Excavator | Ton | 1.2-3 | 2.5-3 | 3-7 | 6-9 | 7-14 | 18-25 | 20-30 | 27-36 | 30-45 | 40-50 | 45-55 | 50-60 |
| Valve Assy's Position | / | Internal | Internal | Internal | Internal | Internal | Internal | Internal | Internal | Internal | Internal | Internal | Internal |
The specifications may vary with different excavators and are subject to change without prior notice for products improvement.
