Basic Info.
Model NO.
LW-RO3.91
Pixel Configuration
1R,1G,1B
Pixel Density
65,536
Scanning Mode
1/16 Scan
System Operating Platform
Windows XP/Windows7
Display Type
LED Video Display
Application
Stage Performance, Advertising, Shopping Guide
IP Rating
IP65
Certification
CE, RoHS, CCC, ETL
Cabinet Size
500mm*500*60mm
Cabinet Material
Die-Casting Aluminum
Module Size(mm)
250X250
LED Chip Spec
SMD 3-in-1
Cabinet Weight
7kg
Trichromatic
1r1g1b
DOT Pitch
6.25,4.81,3.91
Brightness
up 1300CD/M2
Viewing Distance
>4m
Power Consumption
Ave: 120 W
Transport Package
Wooden/Case Carton Box or as Required
Specification
CCC, CE, UL, Rohs
Trademark
LED World, ODM, OEM
Origin
Shenzhen Guangdong, China.
HS Code
8528591090
Production Capacity
10000 Sqm/Month
Product Description
P3.91/ P4.81/P5.95/P6.25 Indoor/Outdoor Video Wall Rental LED Display Screen Panel for Advertising
Features:
1, Adopting SMD3528 LEDs, Big viewing angle(>140°H;>140°W), with a nice flatness appearance of the led screen;
2, Hight brightness>1800CD/SQM(adjustable), The people can see the video/pictures under the sun.
3, Die-casting aluminum molding. Tiny splicing gap, lighter weight(about 8kg) & ultra-thin cabinet.
4, With waterproof glue appearance. Front /rear side IP43, which can be used indoor.
5, Joint, stacking up and hoisting easily & quickly with fast locks.
Product Description:
1. CE,FCC,RoHS,C-Tick approved
2. High quality, High definition, High refresh
3. Superior uniformity, Good display effect
4. 2 years warranty, best after-sales service
5. Video, flash, animation, graphic, text available;
6 . Installation structure drawing offered FOC;
7. Factory visiting and inspecting is welcome;
8. OEM service offered;
9. Models available:
Indoor led display-P2.5mm, P3mm,P3.91, P4mm,P4.81, P5mm, P6mm,P6.25,P10mm etc.
Outdoor led display-P3.91mm,P4.81,P5mm, P6mm, P6.25,P8mm, P10mm, P16mm,P20mm etc.
Parameter:
Product detail:
Applications:
Why choose us?
1, Price Advantage: We have the best competitive price at the market, also have the same even better quality;
2, Quality advantage: From material to finished product, from design to produce, we control all steps;
3, Service advantage: Better service at the same situation, better cooperation at same service, Respond within 24 hours;
4, Excellent R&D team, lower the cost and assure you quality goods;
5, Free training is provided for our customers;
6, Energy saving, low power consumption, and long lifespan 10,000 hours (about 10 years);
Project case:
Product testing:
Our company:
Shenzhen LED World CO., LTD was founded in 2009, focusing on the LED technology research and LED full-color display production, sales, and engineering services for the integration of private high-tech enterprises. The company has professional production equipment and excellent technology, industry veteran, high-quality, high standards of the modern management team, a high level of professional and technical developer, has many years of operating experience and well-trained, a significant number of skilled workers. Company strict implementation of 7 S management standard professional management standards, has passed 3C, CE, FCC, RoHS, ISO9001-2009 quality system certification, reliable quality, advanced technology, automation of form a complete set of products and continuous development of our roots. products are exported to USA, Mexico, Greece, Spain, Italy, UK, Uganda, Nigeria, Russia, India, Turkey, Thailand, Vietnam, Brazil, Australia, etc more than 20 countries and regions, and gained good reputation from the clients.
Workshop:
Package:
Certification:
After-sales maintenance
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature between - 30ºC and 60ºC when you receive the goods from the customs
2. Install and use the product
Please adopt preheating model to light it up and keep 30% brightness for 0.5-2 hours when you use it Keep it work 8 hours or above continually per day will be better.
3. Cleaning
Ensure to use a soft brush to clean the display surface and PROHIBIT any liquid
when doing the cleaning.
Features:
1, Adopting SMD3528 LEDs, Big viewing angle(>140°H;>140°W), with a nice flatness appearance of the led screen;
2, Hight brightness>1800CD/SQM(adjustable), The people can see the video/pictures under the sun.
3, Die-casting aluminum molding. Tiny splicing gap, lighter weight(about 8kg) & ultra-thin cabinet.
4, With waterproof glue appearance. Front /rear side IP43, which can be used indoor.
5, Joint, stacking up and hoisting easily & quickly with fast locks.
Product Description:
1. CE,FCC,RoHS,C-Tick approved
2. High quality, High definition, High refresh
3. Superior uniformity, Good display effect
4. 2 years warranty, best after-sales service
5. Video, flash, animation, graphic, text available;
6 . Installation structure drawing offered FOC;
7. Factory visiting and inspecting is welcome;
8. OEM service offered;
9. Models available:
Indoor led display-P2.5mm, P3mm,P3.91, P4mm,P4.81, P5mm, P6mm,P6.25,P10mm etc.
Outdoor led display-P3.91mm,P4.81,P5mm, P6mm, P6.25,P8mm, P10mm, P16mm,P20mm etc.
Parameter:
| Parameter | P3.91 indoor | P4.81 indoor | P4.81 outdoor | P5.95 indoor | P6.25 indoor | P6.25 outdoor |
| Pixel pitch | 3.91mm | 4.81mm | 4.81mm | 5.95mm | 6.25mm | 6.25mm |
| LED Type | SMD2121 Black | SMD2121 Black | SMD2727 | SMD3528 White | SMD3528 White | SMD3535 White |
| Scan Style | 1/16 | 1/13 | 1/13 | 1/11 | 1/10 | 1/10 |
| Pixel Density | 65,536 | 43,264 | 43,264 | 28,224 | 25,600 | 25,600 |
| Module size(mm) | 250W * 250H | |||||
| Cabinet Size(mm) | 500 W*500 H | 500 W*500 H | 500 W*500 H | 500 W*500 H | 500 W*500 H | 500 W*500 H |
| Pixels/Cabinet | 128x128 | 104x104 | 104x104 | 84x84 | 80x80 | 80x80 |
| Refresh rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
| Brightness | >1300Nits | >1300Nits | >4100Nits | >2000Nits | >1600Nits | >4100Nits |
| Max Power/ panel | 360W | 360W | 360W | 360W | 360W | 360W |
| Weight per cabinet | about 7Kg | about 7Kg | about 8Kg | about 7Kg | about 7Kg | about 8Kg |
| Best viewing distance | ≥4m | ≥4.8m | ≥4.8m | ≥5.9m | ≥6.2m | ≥6.2m |
| Cabinet material | Die-casting aluminum | |||||
| Operating temperature | -30ºC----+60ºC | |||||
| Operating humidity | 10%---%95RH | |||||
| Operating system | Windows XP / Windows 7 /Windows8 /Windows8.1/Windows 10 | |||||
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||||||
Product detail:
Applications:
| Business Organizations | supermarket, shopping mall, office building, industrial park, exclusive agency, chain shop, hotel, restaurant, travel agency, pharmacy, etc. |
| Financial Organizations | banks, security companies, insurance companies, post offices, hospitals, schools, etc. |
| Public Places | subway, airport, train/bus station, gas station, toll station, bookstore, park, exhibition hall, stadium, museum, convention center, ticket center, HR market, lottery center, plaza, commercial building, parking lot, etc. |
| Entertainments | movie theater, fitness hall, country club, night club, massage room, bar, cafe, Internet bar, beauty shop, golf course, casino, etc. |
Why choose us?
1, Price Advantage: We have the best competitive price at the market, also have the same even better quality;
2, Quality advantage: From material to finished product, from design to produce, we control all steps;
3, Service advantage: Better service at the same situation, better cooperation at same service, Respond within 24 hours;
4, Excellent R&D team, lower the cost and assure you quality goods;
5, Free training is provided for our customers;
6, Energy saving, low power consumption, and long lifespan 10,000 hours (about 10 years);
Project case:
Product testing:
Our company:
Shenzhen LED World CO., LTD was founded in 2009, focusing on the LED technology research and LED full-color display production, sales, and engineering services for the integration of private high-tech enterprises. The company has professional production equipment and excellent technology, industry veteran, high-quality, high standards of the modern management team, a high level of professional and technical developer, has many years of operating experience and well-trained, a significant number of skilled workers. Company strict implementation of 7 S management standard professional management standards, has passed 3C, CE, FCC, RoHS, ISO9001-2009 quality system certification, reliable quality, advanced technology, automation of form a complete set of products and continuous development of our roots. products are exported to USA, Mexico, Greece, Spain, Italy, UK, Uganda, Nigeria, Russia, India, Turkey, Thailand, Vietnam, Brazil, Australia, etc more than 20 countries and regions, and gained good reputation from the clients.
Workshop:
Package:
Certification:
After-sales maintenance
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature between - 30ºC and 60ºC when you receive the goods from the customs
2. Install and use the product
Please adopt preheating model to light it up and keep 30% brightness for 0.5-2 hours when you use it Keep it work 8 hours or above continually per day will be better.
3. Cleaning
Ensure to use a soft brush to clean the display surface and PROHIBIT any liquid
when doing the cleaning.
