Basic Info.
Model NO.
BF-V series
Conditions of Use
Land Use
Usage
Common Units
Landuse Type of Unit
Ordinary
Excitation Mode
AC Rotating Exciter
Power Range
68-580kw
Shape
Open/Soundproof/
Engine Source
OEM
Engine Brand
Volvo
Alternator
Stamford/Leroy Somer/Marathon
Control System
Comap/Deepsea
Voltage
400/440V, Hv Available
Frequency
50/60 Hz
Options
ATS, Circuit Breaker, Parallel, Remote Control Pan
Certificates
ISO/Ce/SGS, etc
Warranty
1 Year or 1000 Hours
Transport Package
Plastic Wrapping or Wooden Case
Specification
ISO8528, GB/T2820-1997
Trademark
Baifa
Origin
China
HS Code
85021310
Production Capacity
5000 Sets/Year
Product Description
BAIFA is one of Volvo Penta's largest OEM in China, our cooperation relationship was built back in 1997. For past two decades, Baifa was always pursuing Volvo's three core: Quality, Safety and Environmental Protection.
BAIFA , located in Wuxi, near Shanghai, which is the flourishing area of the world manufacturing, owns one of the largest manufacturing bases of diesel generator sets, marine diesel generator sets, green energy fuel generator sets and lighting towers in Asia, even in globe, covering an area of 60,000 sq.m, and with a 34,000 sq.m. assembly workshop. Baifa has long-term cooperation with world leading companies such as VOLVO PENTA, CUMMINS, MTU, SME MITSUBISHI, BAUDOUIN, STAMFORD and etc. With a range from 8KW to 3000KW, Baifa products cover types of general and special field.
All open gensets can be converted into silent/containerized gensets
For genset model list, please go to the end of this page
BAIFA , located in Wuxi, near Shanghai, which is the flourishing area of the world manufacturing, owns one of the largest manufacturing bases of diesel generator sets, marine diesel generator sets, green energy fuel generator sets and lighting towers in Asia, even in globe, covering an area of 60,000 sq.m, and with a 34,000 sq.m. assembly workshop. Baifa has long-term cooperation with world leading companies such as VOLVO PENTA, CUMMINS, MTU, SME MITSUBISHI, BAUDOUIN, STAMFORD and etc. With a range from 8KW to 3000KW, Baifa products cover types of general and special field.
All open gensets can be converted into silent/containerized gensets
For genset model list, please go to the end of this page
| Powered by VOLVO | 400V, 1500RPM, 50Hz | ||||||||||
| Baifa Model | Standby kVA | Prime kVA | Engine Model | Alternator Stamford | Dimension mm Open Type | Dimension mm Soundproof Type | Fuel Cons 75%(L/H) | Displacement L | Cylinder | Gov |
| BF-V94 | 94 | 85 | TAD530GE | UCI 224G1 | 1840*900*1550 | 2810*1140*1830 | 14.5 | 4.76 | 4 | E |
| BF-V109 | 109 | 100 | TAD531GE | UCI 274C1 | 2150*900*1550 | 2810*1140*1830 | 16.8 | 4.76 | 4 | E |
| BF-V142 | 142 | 130 | TAD532GE | UCI 274E1 | 2150*900*1550 | 2810*1140*1830 | 20.8 | 4.76 | 4 | E |
| BF-V165 | 165 | 150 | TAD731GE | UCI 274F1 | 2410*930*1650 | 3250*1170*1800 | 24.6 | 7.15 | 6 | E |
| BF-V206 | 206 | 188 | TAD732GE | UCI 274H1 | 2550*930*1670 | 3590*1310*2050 | 30.2 | 7.15 | 6 | E |
| BF-V220 | 220 | 200 | TAD733GE | UCI 274H1 | 2550*930*1670 | 3590*1310*2050 | 32.2 | 7.15 | 6 | E |
| BF-V275 | 275 | 250 | TAD734GE | UCDI 274K1 | 2580*930*1670 | 3590*1310*2050 | 41.0 | 7.15 | 6 | E |
| BF-V340 | 340 | 310 | TAD1341GE | S4L1D-D41 | 3100*1120*1788 | 3890*1460*2150 | 45.8 | 12.78 | 6 | E |
| BF-V350 | 346 | 315 | TAD1341GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 45.8 | 12.78 | 6 | E |
| BF-V385 | 385 | 350 | TAD1342GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 50.6 | 12.78 | 6 | E |
| BF-V415 | 415 | 380 | TAD1343GE | S4L1D-F41 | 3100*1120*1788 | 4230*1460*2150 | 55.0 | 12.78 | 6 | E |
| BF-V450 | 450 | 410 | TAD1344GE | S4L1D-F41 | 3100*1120*1788 | 4230*1460*2150 | 60.5 | 12.78 | 6 | E |
| BF-V500 | 500 | 450 | TAD1345GE | S4L1D-G41 | 3100*1120*1788 | 4230*1460*2150 | 66.5 | 12.78 | 6 | E |
| BF-V550 | 550 | 500 | TAD1641GE | S5L1D-C4 | 3400*1270*1974 | 4630*1660*2250 | 73.0 | 16.12 | 6 | E |
| BF-V670 | 660 | 600 | TAD1642GE | HCI 544E1 | 3400*1270*1974 | 4630*1660*2250 | 87.5 | 16.12 | 6 | E |
| BF-V690 | 688 | 625 | TWD1643GE | ECO 40-1.5L (Mecc Alte) | 3400*1400*2100 | 5030*1660*2550 | 90.9 | 16.12 | 6 | E |
| BF-V700 | 700 | 630 | TWD1643GE | HCI 544FS1 | 3400*1400*2100 | 5030*1660*2550 | 91.3 | 16.12 | 6 | E |
| BF-V770 | 770 | 700 | TWD1645GE | S5L1D-G4 | 3400*1400*2100 | 5030*1660*2550 | 102.7 | 16.12 | 6 | E |
| BF-V95-3 | 94 | 85 | TAD550GE | UCI 224G1 | 1840*900*1550 | 2810*1140*1830 | 16.7 | 4.76 | 4 | E |
| BF-V110-3 | 110 | 100 | TAD551GE | UCI 274C1 | 2150*900*1550 | 2810*1140*1830 | 20.8 | 4.76 | 4 | E |
| BF-V145-3 | 143 | 130 | TAD750GE | UCI 274E1 | 2410*930*1650 | 3250*1170*1800 | 23.6 | 7.15 | 6 | E |
| BF-V170-3 | 168 | 152 | TAD751GE | UCI 274F1 | 2410*930*1650 | 3250*1170*1800 | 27.2 | 7.15 | 6 | E |
| BF-V200-3 | 200 | 182 | TAD752GE | UCI 274H1 | 2550*930*1670 | 3590*1310*2050 | 29.6 | 7.15 | 6 | E |
| BF-V220-3 | 220 | 200 | TAD753GE | UCI 274H1 | 2550*930*1670 | 3590*1310*2050 | 32.1 | 7.15 | 6 | E |
| BF-V275-3 | 275 | 250 | TAD754GE | UCDI 274K1 | 2580*930*1670 | 3590*1310*2050 | 42.5 | 7.15 | 6 | E |
| BF-V360-3 | 358 | 325 | TAD1351GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 49.7 | 12.78 | 6 | E |
| BF-V400-3 | 400 | 350 | TAD1354GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 55.0 | 12.78 | 6 | E |
| BF-V400-3 | 415 | 360 | TAD1354GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 55.0 | 12.78 | 6 | E |
| BF-V420-3 | 420 | 380 | TAD1354GE | S4L1D-F41 | 3100*1120*1788 | 4230*1460*2150 | 58.1 | 12.78 | 6 | E |
| BF-V450-3 | 450 | 410 | TAD1355GE | S4L1D-F41 | 3100*1120*1788 | 4230*1460*2150 | 63.0 | 12.78 | 6 | E |
| BF-V500-3 | 500 | 450 | TAD1650GE | S4L1D-G41 | 3400*1270*1974 | 4630*1660*2250 | 68.9 | 16.12 | 6 | E |
| BF-V550-3 | 550 | 500 | TAD1651GE | S5L1D-C4 | 3400*1270*1974 | 4630*1660*2250 | 73.0 | 16.12 | 6 | E |
| BF-V660-3 | 660 | 600 | TWD1652GE | HCI 544E1 | 3400*1400*2100 | 5030*1660*2550 | 94.1 | 16.12 | 6 | E |
| BF-V690-3 | 688 | 625 | TWD1653GE | ECO 40-1.5L (Mecc Alte) | 3400*1400*2100 | 5030*1660*2550 | 97.9 | 16.12 | 6 | E |
| BF-V700-3 | 700 | 630 | TWD1653GE | HCI 544FS1 | 3400*1400*2100 | 5030*1660*2550 | 98.2 | 16.12 | 6 | E |
| BF-V720-3 | 720 | 650 | TWD1653GE | ECO 40-2L (Mecc Alte) | 3400*1400*2100 | 5030*1660*2550 | 101.7 | 16.12 | 6 | E |
| BF-V720-3 | 720 | 650 | TWD1653GE | HCI 544F1 | 3400*1400*2100 | 5030*1660*2550 | 101.4 | 16.12 | 6 | E |
| Powered by VOLVO | 440V, 1800RPM, 60Hz | ||||||||||
| Baifa Model | Standby kVA | Prime kVA | Engine Model | Alternator Stamford | Dimension mm Open Type | Dimension mm Soundproof Type | Fuel Cons 75%(L/H) | Displacement L | Cylinder | Gov |
| BF-V142-60 | 145 | 131 | TAD532GE | UCI 274D1 | 2150*900*1550 | 2810*1140*1830 | 22.5 | 4.76 | 4 | E |
| BF-V206-60 | 220 | 200 | TAD732GE | UCI 274G1 | 2550*930*1670 | 3590*1250*2050 | 34 | 7.15 | 6 | E |
| BF-V220-60 | 248 | 223 | TAD733GE | UCI 274H1 | 2550*930*1670 | 3590*1250*2050 | 38,.1 | 7.15 | 6 | E |
| BF-V275-60 | 286 | 260 | TAD734GE | UCDI 274J1 | 2600*1120*1761 | 3590*1250*2050 | 39 | 7.15 | 6 | E |
| BF-V350-60 | 375 | 340 | TAD1341GE | S4L1D-D41 | 3100*1120*1788 | 4230*1460*2150 | 51.6 | 12.78 | 6 | E |
| BF-V385-60 | 440 | 400 | TAD1342GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 61.1 | 12.78 | 6 | E |
| BF-V415-60 | 450 | 410 | TAD1343GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 62.5 | 12.78 | 6 | E |
| BF-V450-60 | 500 | 455 | TAD1344GE | S4L1D-F41 | 3100*1120*1788 | 4230*1460*2150 | 69.2 | 12.78 | 6 | E |
| BF-V550-60 | 642 | 570 | TAD1641GE | HCI 544D1 | 3400*1270*1974 | 4630*1660*2250 | 87.7 | 16.12 | 6 | E |
| BF-V670-60 | 688 | 625 | TAD1642GE | HCI 544E1 | 3400*1270*1974 | 4630*1660*2250 | 95.3 | 16.12 | 6 | E |
| BF-V700-60 | 750 | 688 | TWD1643GE | HCI544E1 | 3400*1400*2100 | 5030*1650*2550 | 102.2 | 16.12 | 6 | E |
| BF-V770-60 | 800 | 725 | TWD1645GE | HCI 544FS1 | 3400*1400*2100 | 5030*1650*2550 | ||||
| BF-V95-3-60 | 107 | 97 | TAD550GE | UCI 224G1 | 1840*900*1550 | 2810*1140*1830 | 19.7 | 4.76 | 4 | E |
| BF-V110-3-60 | 125 | 115 | TAD551GE | UCI 274C1 | 2150*900*1550 | 2810*1140*1830 | 23.9 | 4.76 | 4 | E |
| BF-V145-3-60 | 162 | 144 | TAD750GE | UCI 274E1 | 2410*930*1650 | 3250*1170*1800 | 27 | 7.15 | 6 | E |
| BF-V170-3-60 | 190 | 170 | TAD751GE | UCI 274F1 | 2410*930*1650 | 3250*1170*1800 | 32.3 | 7.15 | 6 | E |
| BF-V200-3-60 | 220 | 200 | TAD752GE | UCI 274G1 | 2550*930*1670 | 3590*1250*2050 | 39.1 | 7.15 | 6 | E |
| BF-V220-3-60 | 253 | 230 | TAD753GE | UCI 274H1 | 2550*930*1670 | 3590*1250*2050 | 38 | 7.15 | 6 | E |
| BF-V275-3-60 | 287 | 260 | TAD754GE | UCDI 274J1 | 2580*930*1670 | 3590*1250*2050 | 49.2 | 7.15 | 6 | E |
| BF-V360-3-60 | 375 | 340 | TAD1351GE | S4L1D-D41 | 3100*1120*1788 | 4230*1460*2150 | 56.1 | 12.78 | 6 | E |
| BF-V400-3-60 | 437 | 400 | TAD1352GE or TAD1354GE | S4L1D-E41 | 3100*1120*1788 | 4230*1460*2150 | 64 | 12.78 | 6 | E |
| BF-V500-3-60 | 568 | 516 | TAD1650GE | S4L1D-G41 | 3400*1270*1974 | 4630*1660*2250 | 81.3 | 16.12 | 6 | E |
| BF-V550-3-60 | 640 | 580 | TAD1651GE | HCI 544D1 | 3400*1270*1974 | 4630*1660*2250 | 85.7 | 16.12 | 6 | E |
| BF-V100-4F | 102 | 92 | TAD570VE | UCI 224F1 | 1840*900*1550 | NA | ||||
| BF-V130-4F | 130 | 117 | TAD571VE | UCI 274C1 | 2150*900*1550 | NA | ||||
| BF-V165-4F | 165 | 150 | TAD572VE | UCI 274E1 | 2150*900*1550 | NA | ||||
| BF-V195-4F | 194 | 176 | TAD871VE | UCI 274E1 | 2550*930*1670 | NA | ||||
| BF-V220-4F | 220 | 200 | TAD872VE | UCI 274F1 | 2550*930*1670 | NA | ||||
| BF-V250-4F | 253 | 228 | TAD873VE | UCI 274H1 | 2650*930*1670 | NA | ||||
| BF-V290-4F | 292 | 263 | TAD1171VE | UCDI 274J1 | 2800*1000*1670 | NA | ||||
| BF-V315-4F | 317 | 286 | TAD1371VE | UCDI 274J1 | 3100*1120*1788 | NA | ||||
| BF-V350-4F | 352 | 317 | TAD1372VE | S4L1D-C14 | 3100*1120*1788 | NA | ||||
| BF-V385-4F | 387 | 348 | TAD1373VE | S4L1D-D14 | 3100*1120*1788 | NA | ||||
| BF-V420-4F | 422 | 380 | TAD1374VE | S4L1D-D14 | 3100*1120*1788 | NA | ||||
| BF-V455-4F | 457 | 411 | TAD1375VE | S4L1D-E14 | 3100*1120*1788 | NA | ||||
| BF-V510-4F | 512 | 461 | TAD1671VE | S4L1D-F14 | 3400*1270*1974 | NA | ||||
| BF-V590-4F | 589 | 530 | TAD1672VE | S4L1D-G14 | 3400*1270*1974 | NA | ||||
| BF-V700-4F | 694 | 638 | TWD1672GE | HCI 544D1 | 3400*1400*2100 | NA | ||||
| BF-V700-4F | 700 | 638 | TWD1672GE | HCI 544E1 | 3400*1400*2100 | NA | ||||
| BF-V780-4F | 781 | 713 | TWD1673GE | HCI 544E1 | 3400*1400*2100 | NA | ||||
