Basic Info.
Model NO.
KG-HY-S100F
Form
All- packaged Type
Operation Voltage
Low Voltage
Size
601*285*144mm
Application Range
All
Shell Material
Plastic
Shell Protection Grade
IP54
Brand
Cango
Place of Origin
Zhejiang, China (Mainland)
Model Number
Kg
Protection Level
IP54
External Size
601*285*144mm
Installation Type
Wall Mounted/Pole Mounted
Material
Plastic
Installation Location
Indoor/Outdoor
Frequency
50Hz or 60Hz
Life Expectancy
More Than 30 Years
Insulation Resistance
30ka
Trademark
CANGO
Origin
China
HS Code
3926909090
Production Capacity
1000000000
Packaging & Delivery
Package Size
610.00cm * 300.00cm * 150.00cm
Package Gross Weight
3.000kg
Product Description
| Technical Specification | |
| Installation Network: | LV: AC220V,AC380V |
| Installation type: | wall mounted/polc mounted |
| Installation location: | Indoor/outdoor |
| Frequency: | 50Hz or 60Hz |
| Main busbar rated short time withstand current low: | 30kA |
| Insulation resistance: | ≥20MΩ |
| Rated insulation voltage UI: | 800V |
| Material: | PC+ABS |
| Protection Class: | IP54 |
| Life Expectancy: | ≥30 years |
| Main busbar rated current In: | 10A~250A |
| Dimension(LxWxD): | 601*285*144mm |
| Model | Position | Name | Specification | Qty |
| KG-S101A | Front of meter | Disconnect switch | HUH17-100/2P63A | 1 |
| Back of meter | MCB | DZ47-2P/C32A | 1 | |
| KG-S102A | Front of meter | Disconnect switch | HUH17-100/2P63A | 1 |
| Back of meter | Terminal Box(Two in and two out) | AFJ6/JHD-8/A | 1 | |
| KG-S103A | Front of meter | Circuit breaker | DZ47-2P/C32A | 1 |
| Back of meter | RCCB | DZ47LE-32/1N | 1 |
What can we do for you?
1)We offer sample for free
2)Competitive Price( Factory direct price) .
3)On time delivery
4) Good customers service
5) Professional Technology
6) Dimensions: As customers' requirement
7) Quality Control through the whole Manufacturing process
a. Check the material before the production
b. Have the random inspection during the production
c. Make the 100% inspection before the shipment
If you are interested in our products , please feel free to contact with us ,we will try our best to meet your demand.
In addition to this model of the product, we have the following products to choose from.
