6 Ways Electrical Distribution Box Transparent Plastic Box Gnb Power Distribution Box Size

Get the best quality electrical distribution boxes from our factory. Our transparent plastic GNB power distribution box comes in various sizes for all your power distribution needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
GNB 1006
Application Range
Power Plants
Shell Material
Stainless Steel
Shell Protection Grade
IP30
Brand
Singi
Product Name
Electrical Distribution Box Size
Certificates
UL/CE/CB
Keyword
Power Distribution Box
Material
Cold-Rolled Steel
Protection Degree
IP 30
Color
Ivory-White
Transport Package
Standard Exporting Carton
Trademark
SINGI
Origin
Zhejiang, China
Production Capacity
30000 Piece/Pieces Per Month

Product Description

6 Ways Electrical Distribution Box Transparent Plastic Box  Gnb Power Distribution Box Size

 Intelligent Building Electrical Products  |  Switches And Sockets  |  Home Security Cable



PRODUCT INTRODUCTION



GNB series flush type and surface distribution boxes/distribution boards are mainly used in the circuit Of  AC 50Hz, rated



voltage 220V/380V, and acted to install the modular combination equipment. It  is widely used in the family, high building,



house, station, port, airport, commercial house, hospital,cinema, enterprises and so on occasion. The plastic unit of the GNB



Series Flush type and Surface type distribution boxes adopts ABS flame-proof material with the characteristics of flame-proof,



impulse proof excellent insulation property and so on.



FEATURES



.Standard IEC60670



.Protection degree IP30;



.Merlin Gerin type;



.4,6,9,13,15,18,26,36,54,72 modules available;



.4-26circuits single row, 36 circuits double rows ,54-72 circuits three rows available;



.Flush and surface installation available;



.Transparent and opaque available;



.Cambered and streamlined surface;



.Convenient bound opening key;



.Flame-retardant PC panel ,ivory-white ,never fade ,ABS frame;



.The installation screw is occlusion ,elegant;



.Terminal with flame-retardant shield, wiring is safe and reliable;



.The base is good cool-rolled steel plate,single row ,box is 0.8mm thickness, double



or multi rows 1.0mm thickness and the surface is plastic casted;



.Good zinc-plated din to prevent from rust.



.Adjustable DIN rail ,adjustable depth;



.Certificates CE &CB.



SPECIFICATION



Model

Remark

GNB1004

4cicuits surface installation;

4cicuits flush installation;

GNB1006

6cicuits surface installation;

6cicuits  flush  installation;

GNB1009

9cicuits surface installation;

9cicuits flush installation;

GNB1013

13cicuits surface installation;

13cicuits flush installation;

GNB1015

15cicuits surface installation;

15cicuits flush installation;

GNB1018

18cicuits surface installation;

18cicuits flush installation;

GNB1026

26cicuits surface installation;

16cicuits flush installation;

GNB1030

30cicuits surface installation;

30cicuits flush installation;

GNB1036

36cicuits surface installation;

36cicuits flush installation;

GNB1045

45cicuits surface installation;

45cicuits flush installation;

GNB1054

54cicuits surface installation;

54cicuits flush installation;

GNB1072

72cicuits surface installation;

72cicuits flush installation;



Remark:GNB1009/GNB1013/GNB1018 can be plastic type
